Vibratory Pan Feeder Hopper Dimensions
| Model Number | Capacity CU-FT | A | B | BB | C | D | E | F | G |
|
5500A.1
|
2/3 | 20 1/4 | 13 1/4 | 13 1/4 | 11 5/8 | 7 1/4 | 5 | 12 3/4 | 8 1/2 |
|
5500B.1
|
2 | 25 7/32 | 18 1/4 | 18 1/4 | 11 5/8 | 7 1/4 | 6 1/2 | 12 3/4 | 8 1/2 |
|
5500C.1
|
5 | 30 13/16 | 24 1/4 | 24 1/4 | 13 5/8 | 7 1/4 | 7 1/2 | 12 3/4 | 8 1/2 |
|
5500D.1
|
6 | 38 1/2 | 30 1/4 | 30 1/4 | 16 5/8 | 8 1/2 | 10 | 15 5/16 | 19 |
|
5500BR
|
2 | 25 7/32 | 18 1/4 | 18 1/4 | 11 5/8 | 7 1/4 | 6 1/2 | 12 3/4 | 8 1/2 |
| Model Number | Series |
Capacity (Cubic Ft) |
Discharge Height (Inches) | Input Voltage | Input Current | Shipping Weight (Pounds) |
|
5500S.1
|
S | 1/4 | 5-11 | 120 VAC | 0.75 A | 25 |
