Model 30 Feeder Base Unit for 30" - 36" Vibratory Bowls

RoHS compliant
Model 30 standard base unit

Model 30 standard base unit dimensions

All dimensions are in inches. Top Mount: (6) 3/8-16 tapped on 21 1/4'' diameter circle; Bottom Mount: Available as an Option



Model Number Rotation Input Voltage Input Current Use Controller

30CC.1

CC 120 VAC 12.0A Model 6000.1

30CC.2

CC 240 VAC 5.0A Model 6000.2

30CK.1

CK 120 VAC 12.0A Model 6000.1

30CK.2

CK 240 VAC 5.0A Model 6000.2

*CC stands for Counter-clockwise
*CK stands for Clockwise

Spring Angle 25°
Shipping Weight 876 pounds
Foot Locator 7951
Single Stud Foot - Standard 2008
Single Stud Foot - Soft
Double Stud Foot - Alternative
Bumper Style Foot - Hard
Bumper Style Foot - Soft
Locator Style Foot 3008
